BMC-X-840 Chemical Storage
Occupancy fire-rated hazmat storage for flammable liquids. 7 sizes up to 30 qm storage area.
DENIOS
Description
Room paneling and door(s) with up to 240 minutes fire resistance. Installation indoors and outdoors on customer-provided concrete pad. Complies with the national standard GB50016 and landmark DB3204, developed based on the approval by DIBt (Germany) and IBS (EU) with adaptions.
- Occupancy fire-rated hazmat storage for flammable liquids
- Room paneling and door(s) with up to 240 minutes fire resistance
- Flexible installation indoors or outdoors on customer-provided concrete pad
- Various door designs (1-/2-wing) and positions (short side/long side, centered/off-centered) selectable
- Easy access with low door
- Integrated steel spill pallet with removable hot dip galvanised grids
- Sealing tested in accordance with EN ISO 3452-1 with factory test certificate
- An equipotential bonding connection point is provided as standard for avoiding static charges
- Delivered ready assembled, ready for the customer to secure to the ground
- Includes crane eyes for easy unloading
- Points to consider for the storage of flammable substances: equipotential bonding / earthing - technical ventilation
Models
BMC-M 240
Outer dimensions: 2590 x 2510 x 2400
Inner dimensions: 2250 x 2175 x 2060
Weight: 1950 KG
BMC-M 360
Outer dimensions: 3790 x 2510 x 2400
Inner dimensions: 3450 x 2175 x 2060
Weight: 2420 KG
BMC-X 480
Outer dimensions: 4680 x 2865 x 2800
Inner dimensions 4340 x 2530 x 2460
Weight: 3350 KG
BMC-X 600
Outer dimensions: 6060 x 2865 x 2800
Inner dimensions: 5720 x 2530 x 2460
Weight: 4280KG
BMC-X 840
Outer dimensions: 8460 x 2865 x 2800
Inner dimensions: 8120 x 2530 x 2460
Weight: 5240 KG
BMC-X 1000
Outer dimensions: 10000 x 2865 x 2800
Inner dimensions: 9660 x 2530 x 2460
Weight: 6480 KG
BMC-X 1200
Outer dimensions: 12000 x 2865 x 2800
Inner dimensions: 11660 x 2530 x 2460
Weight: 8030 KG
