High-Purity Six-Port Single-Stage Low-Pressure Cylinder Regulator
The DruvaPUR 20 m3 Series high-purity six-port single-stage low-pressure cylinder regulator is used in gas supply systems for pure, inert, flammable, oxidising, corrosive gases, and/or toxic gases and gas mixtures up to a maximum gas purity of 6.0.
GCE Druva
Description
When precision meets reliability, you get the Druva high-purity six-port single-stage low-pressure regulator. Featuring a Hastelloy diaphragm tightening system, it ensures a tight, leak-proof seal to prevent gas leakage. Its compact design allows for easy installation in tight spaces, while superior pressure adjustment gives you precise control over gas flow. Available in multiple international cylinder connections and with a range of options to suit your specific needs, this high-purity single-stage regulator is built for performance and flexibility.
- Hastelloy diaphragm tightening system for superior leak protection and reliable atmospheric sealing.
- Space-saving compact design for easy integration in confined areas.
- Excellent pressure adjustment for consistent and accurate gas flow control.
- Available with multiple options like shut-off valve, regulating valve, purge valve, and more – see datasheet.
- Available with several international cylinder connections – refer to the top-level drawings.
- Designed and approved regarding ISO 7291.
- Relief valve option available on the delivery pressure side.
- Electrostatic chargeability test:
- Fulfils requirements according to DIN EN ISO 80079-36, IEC TS 60079-32-1, and German TRGS 727.
- Usable in EX-areas zones 1 and 2 for gases with explosion risk group I, IIA, IIB, and IIC.
