LAF Trolley
LAF Trolley is a mobile laminar airflow workstation designed to provide a controlled, clean-air environment for sample handling and laboratory processes requiring contamination control.
FASTER
Description
The LAF Trolley was specially developed for the protected transport and temporary storage of sensitive products in cleanroom and GMP environments. Whether for transfer between separate zones (e.g. before or after autoclaving) or as mobile storage under controlled conditions - the LAF Trolley offers reliable product protection in cleanroom class ISO 5 in accordance with NF, EN, ISO 14644-1.
- Maximum product protection on the move - even without a centralised air supply
- Ideal for critical transfer points and mobile processes
- Self-sufficient, flexible, hygienic - suitable for GMP and cleanroom applications
- Uncompromising filtration and airflow technology
- Robust stainless steel construction - low-maintenance and durable
Technical features at a glance
Air flow and protective function
- Horizontal laminar airflow ISO 5
- Flow from the rear plenum to the loading door via shelves and rails
- Uniform airflow with constant overpressure in the interior
- Continuous product protection during transport, storage and dwell time
Ventilation system
- High-performance blower from EBM Papst - energy-efficient and reliable
- Automatic air speed control with digital anemometer and LCD display
Filtration
- Multi-stage filter system:
G3 pre-filter (in accordance with EN 779) with 80-90 % retention capacity
HEPA H13 filter (optional H14) in accordance with CEN EN 1822 - highly efficient particle separation
Quick-release system for tool-free filter maintenance
Power supply
- Self-sufficient UPS unit with maintenance-free dry battery
- Operating time when fully charged: up to 100 minutes
- Charge status indicator on the trolley
- Note: Device should remain permanently connected to the power supply in order to be ready for operation at all times
- Optional: dual UPS system for longer operating autonomy or safety-critical applications
Construction and mobility
- Made entirely of AISI 304L 4B stainless steel (Scotch-Brite surface) - suitable for cleanrooms, smooth surfaces with <0.8 µm roughness
- Side panels and covers optionally made of stainless steel or 8 mm safety glass
- Interior with stainless steel support rails to accommodate shelves
- number of shelves variable depending on interior height and customer requirements - Handles at the front and rear for safe manoeuvring
- Hinged or removable front panel - quick access to the interior
- 360° swivelling castors with locking function - maximum manoeuvrability with secure footing
- Backlit main switch
Expandable options and accessories
- UV air purification unit for additional microbiological safety
- H14 filter upgrade for the highest filtration requirements
- Double UPS for extended self-sufficient running time
- Side sliding panes for quick access to stored products
- Removable support rails - autoclavable for maximum hygiene
- Stainless steel shelves available as accessories
- Special dimensions or special equipment can be realised on request
Typical applications of the LAF trolley
- Transport of sterilised products between autoclave and cleanroom
- Storage of contamination-sensitive materials during internal logistics
- Intermediate buffering in material airlocks or cleanroom zones
- Flexible locations where there is no fixed infrastructure for product protection
